H30B Zemic (Tinhang) Shear Beam Load Cell

Brand: Zemic (Tinhang), China
  • H30B load cells are available for manifold accurate
    measurement in the capacities 0.5t~10t and 1K~20K.
  • Alloy steel, potted by adhesive inside, oil-proof, waterproof
    and anti-corrosion, suitable for all kinds of environments.
  • Single shear beam, low profile and easy installation.
  • Suitable for electronic platform scale, hopper scale, and
    other electronic weighing devices.
  Hurry up! Sale end in:
  •  Delivery & Return

    Delivery Policy

    POLICIES CAN BE CHANGED AT ANY TIME WITHOUT PRIOR NOTICE. At Wazan.pk, we strive to provide you with a seamless delivery experience. Please note that all delivery charges will be bear by the customer. We understand the importance of flexibility, which is why we offer you the choice of selecting your preferred Courier/Cargo service for delivery. In the absence of your preferred choice, we will ensure to select the best possible alternative for efficient delivery. It’s important to note that delivery timing will be based on the Courier/Cargo service chosen by you. In the event of refunds or exchanges, please be advised that any delivery charges incurred will be the responsibility of the customer. We are committed to delivering your orders in a timely and reliable manner, ensuring your satisfaction with every purchase, all at affordable prices.

    Return and Exchange Policy

    POLICIES CAN BE CHANGED AT ANY TIME WITHOUT PRIOR NOTICE. At Wazan.pk, we strive to ensure your complete satisfaction with every purchase. If you’re not satisfied with your order for any reason, we’re here to help.
  •  Ask a Question
  ... people are viewing this right now
Compare
  Share
Guaranteed Safe CheckoutTrust
View Product Information

H30B load cells are available for manifold accurate measurement in the capacities 0.5t~10t and 1K~20K.
Alloy steel, potted by adhesive inside, oil-proof, waterproof and anti-corrosion, suitable for all kinds of environments.
Single shear beam, low profile and easy installation.
Suitable for electronic platform scale, hopper scale, and other electronic weighing devices.

H30B-Datasheet

0.00
0 reviews
5
0
4
0
3
0
2
0
1
0
Thank you! Your review has been submitted
Be the first to review “H30B Zemic (Tinhang) Shear Beam Load Cell”

Your email address will not be published. Required fields are marked *

This field is required.

This field is required.

This field is required.

Be the first to review “H30B Zemic (Tinhang) Shear Beam Load Cell”

Reviews

There are no reviews yet.

TECHNICAL SPECIFICATION

Capacity t 0.5/1/1.5/2/2.5/3/5/10
Klb 1/1.5/2/2.5/3/4/5/7.5/10/15/20
Output sensitivity mV/V 3.0±0.003 2.0±0.002
Combined error %F.S ≤±0.05
Creep %F.S/30min ≤±0.03
Temperature effect on sensitivity %F.S/10°C ≤±0.05
Temperature effect on zero %F.S/10°C ≤±0.05
Input resistance Ω 410±30Ω
Output resistance Ω 352±2Ω
Insulation resistance MΩ ≥5000 (50V)
Zero balance %F.S ±1.5 ±1
Temperature, compensated °C -10~+40
Temperature, operating °C -20~+60
Excitation, recommended V 5~12 (DC)
Excitation, max. V 18 (DC)
Safe overload %F.S 150
Ultimate overload %F.S 200
